Performance Range:

• Max. Head: 45m
• Max. Flow: 5.0m3/h
• Power: 550w to 650w

Operating Limits:

• Thin, clean, non-condensation, non-flammable, non-explosive, without solid particles or fibers liquid.
• The volume ratio of solid impurities not more than 0.1%
• Max. solid size: 0.2mm
• Max. liquid temperature: 70°C
• Ambient temperature: 0°C to 40 °C
• PH valve: 6.5 to 8.5
• Max. relative humidity: 85%
• Max. working pressure: 8 bar
• Max. inlet pressure: 3 bar

Materials:
ABS casing, stainless steel pump body, impeller and shaft, silicon carbon to graphite
mechanical seal.

Application:

• Domestic water supply
• Industrial water supply and circulation
• Cooling system
• Air conditioning system
• Commercial water supply and pressure boosting
